In "SSID Choice" you enter the name ALFA_AP. The ALFA R36 is now connected to the external WiFi network via the connected WiFi USB adapterĤ) On the following page we are coming now to the configuration of the WiFi network, which the R36 is transmitting, so that you can connect to it with your personal device. If the WiFi network is not encrypted just skip the last step. In case the WiFi network you want to connect with is encrypted, please type in the key of the WiFi network into passphrase in the security mode. Please choose here the network you want to be connected with und click then "Select". Therefore please choose in the administration panel "Easy Setup" and click then "USB Wireless Adapter". After R36 is booted again you will directly land again on the administration panel.ģ) The R36 can now be configured. During this time please do not disconnect the power supply of the device. It can take up to 5 minutes until the firmware is updated and the device is booted again.
ALFA NETWORK BOOSTER UPDATE
Here you need to confirm the firmware update one more time. Set a tick at "Load Factory Defaults" and click "Upload". In the administration panel of the R36 in "Firmware Update" click now the button "search", choose the R36-ALFA-al-2.32.img file, which you just downloaded. The configuration Later on the administration can also be made through WiFi. In case another version than 2.32 is installed, please click with the right mouse button on the following link and click then "Save as…" Firmware-Download.ĬAUTION: The firmware update is only working if the R36 is connected via a network (LAN) cable.
ALFA NETWORK BOOSTER SOFTWARE
Please check what is written at software version.įor the operation with the obove mentiones USB WiFi adapters the following version of firmware is needed: 2.32 – There is no need for adaptation of the firmware version if the needed version is already installed. In the menu "Advanced" please choose "Management".
ALFA NETWORK BOOSTER PASSWORD
User name and password are set per standard on the following value. It is set per standard on the following value: 192.168.2.1 Therefore please open a web browser of your choice and type in the address line the IP-address of ALFA R36. To determine if an update is needed, please log in to the administration panel of the ALFA R36. Later on the administration can also be made through WiFi.Ģ) Connect the WiFi USB adapter to the USB port of the ALFA R36. The initial configuration needs to be made via network cable. It is located on the backside next to the power connector.
Therefore please connect the ethernet port of the computer directly to the LAN connector of the R36. To make use of the ALFA R36 router in combination with one of the mentioned WiFi USB adapters it can be necessary to perform an update of the firmware of the ALFA R36.ġ) Connect the ALFA R36 to you PC or notebook via ethernet network cable. In the following we will show you an illustrated instruction for installation and configuration of ALFA R36 as range extender in combination with a ALFA AWUS036NEH / AWUS036NH / AWUS036NHR / UBDO-n / Tube-UN (Cyliner-150), Tube-UV, UBDO-UV or our WiFi yacht set.
